Built to specification for your equipment and to fit any suitable truck, the Dynahyd system is designed, engineered, manufactured and assembled at our own location in Concord, Ontario. Fabricam Manufacturer of the Dynahyd Roll Off System, now under new ownership and management, offers two types of systems: the hydraulic-winch and the all hydraulic system. The choice of lifting system is entirely dependent on the particular application of the system in your business. Working with our sales staff and engineers, we will ensure you get the right system to fit your needs.

All Fabricam systems are manufactured to customer specifications.

Standard components used, include:

• Reinforced Rigid Tubular Tilt-N-Load Frame
• 4" x  8" x 3/8" H.S.S Steel
• 42000 lbs. minimum load capacity
• QT100 formed deck
• Fill length pivot pin
• Tail end heavy duty roller

• In-cab and External Hydraulic Controls
• 30000 lbs. Hydraulic Tulsa Winch
• 3/4" x 50' Steel Rope-Core Cable
• Heavy Duty Power Take Off
• 2 Lifting Cylinders

• Hydraulics
• Hydraulic reservoir with (optional) integrated oil level / temperature gauge
• Hydraulic supply and return filtration
• System overload protection

• Low Profile, Frameless All-Steel Deck
• 36" loading ramp sheeted with checker plate to enable easy ground load
• Optional hydraulic tail winch
• Available in custom design to fit individual requirements

• Steel Headboard (built to consumer specifications)
• Including screen and chain hooks
• Deck and Sub-Frame Painted Black Using Rust Resistant Paint

Other Accessories

• Mud Flaps
• Tail Light Guards
• Optional LED lights on request
• Custom Tool Box

Custom-built systems to fit the truck of your choice

• Ford
• Mack
• FreightLiner
• Kenworth
• Man
• Mitshubishi
• Mercedes-Benz
• Western Star Trucks
• Volvo
• Scania
• Peterbilt

Financing Available
